Corelight
The following Corelight integrations are available for use with LogScale:
Installing Corelight Packages
To install the Corelight packages:
Go to the humio-organization-corelight-demo view.
Click on the
buttonGo to the Marketplace under the tab in your view.
Choose the
corelight/sensor
package from the package summary.Click the
button.
Repeat the process with the corelight/threathuntingguide package.
To start querying the data, see Sample Queries.
Data Format
The sample data is derived from Corelight installation dataset, parsed and presented within the Corelight repository. The data has been extracted from a running Corelight capture service and includes an array of different information, triggers, and threats from the captured data.
The repository content consists of 74 minutes data, replayed on a loop so that the information is active within the repository. Although the data is repeated, the format and structure of the information provides an ideal resource for running and executing queries to understand the format and output.
Common Event Data
Event data has been parsed and tagged from raw JSON presented by Corelight. Event data contains the following core information for each event:
Source and Destination IP address and Port
Top-level Protocol (UDP or TCP)
Service-level Protocol (dns, ssl, http)
Bytes sent and received
Hardware address for source and destination
Timestamps for the packet and when it was recorded
Duration of the connection
Protocol specific data
Corelight recognises a number of distinct types of data where additionals fields and information are identified and included. The following are examples only:
For DNS the requested query type (e.g. address, server, MX (mail) record)
For HTTP, if identifiable, the source and content of the data
For DHCP, lease, IP address, MAC address and whether a specific name or ID is used
For file transfer, the file size, name, and digest contents
Alerts or triggers identified by Corelight thread detection:
Alert level
Category, including a description
The raw data from Corelight is presented as JSON, for example:
{
"_path": "conn",
"_system_name": "SmartPCAP_192_168_5_1",
"_write_ts": "2022-02-18T16:07:48.737324Z",
"community_id": "1:WOlQiyEP/B3qO3ib+RwAYV06Av8=",
"conn_state": "S0",
"corelight_shunted": false,
"duration": 0.00754499435424805,
"history": "S",
"id.orig_h": "10.9.18.101",
"id.orig_p": 49218,
"id.resp_h": "66.96.147.100",
"id.resp_p": 587,
"local_orig": true,
"local_resp": false,
"missed_bytes": 0,
"orig_bytes": 0,
"orig_ip_bytes": 152,
"orig_l2_addr": "00:08:02:1c:47:ae",
"orig_pkts": 3,
"proto": "tcp",
"resp_bytes": 0,
"resp_cc": "US",
"resp_ip_bytes": 0,
"resp_l2_addr": "20:e5:2a:b6:93:f1",
"resp_pkts": 0,
"spcap.rule": 6,
"spcap.trigger": "all-unencrypted",
"spcap.url": "https://192.168.5.1/spcap/v1/?uid=CxZD5YDQVXFfwHSW7",
"ts": "2022-02-18T16:07:43.737232Z",
"uid": "CxZD5YDQVXFfwHSW7"
}
Within the sample repository data, the raw JSON has been parsed into a combination of tags and fields.
Common fields from the data parsed into the events within LogScale:
#path
Primary event type, this indicates the main log event, for example HTTP, SSL, raw TCP. See Event Types (
#path
).Unique ID for each event
uid
A unique ID for the session, which may include multiple events. This can be used to identify a sequence of communication that may include multiple types of events. See Session Identifier (
uid
).ts
Timestamp for the event, to the nearest millisecond.
Event Types (#path
)
The events consist of the following major event types (identified
through the event #path
tag):
conn
IP, TCP, UDP and ICMP connection details
dce_rpc
DCE/RPC communication information
dhcp
DHCP lease information
dns
DNS query and response details
files
File analysis results
notice
Notices of identified information generated by the Corelight device
smartpcap-stats
SmartPCAP statistics from th Corelight device
ssl
SSL handshakes
x509
X.509 certificate information
For more information on the specific fields within each event type, consult the Zeek log files reference.
To get a full list of all the available event types in the sample data you can use:
groupby(#path)
| sort(_count)
This will product the following list:
#path | _count |
---|---|
conn" | 626182 |
dns | 309720 |
files | 99111 |
http | 65871 |
ssl | 61076 |
ntp | 25809 |
dhcp | 25648 |
notice | 20378 |
smartpcap-stats | 19708 |
x509 | 15073 |
intel | 11615 |
corelight_overall_capture_loss | 9855 |
suricata_corelight | 9245 |
weird | 4971 |
dce_rpc | 2012 |
specific_dns_tunnels | 1712 |
smartpcap | 1007 |
etc_viz | 811 |
rdp | 679 |
ssh | 410 |
smb_mapping | 379 |
kerberos | 367 |
smtp | 286 |
smtp_links | 268 |
ntlm | 208 |
smb_files | 184 |
reporter | 177 |
software | 163 |
dpd | 113 |
pe | 103 |
snmp | 95 |
ftp | 39 |
meterpreter | 10 |
meterpreter_headers | 10 |
radius | 9 |
stepping | 7 |
dga | 6 |
generic_icmp_tunnels | 2 |
tunnel | 2 |
log4j | 1 |
Session Identifier (uid
)
The uid
field identifies events related to an
individual session. The duration of the session depends on the
communication involved. For example, a DNS query might consist of only
two events (the request and the response) or thousands of events across
a variety of different types.
You can see this by searching the uid
CCsBUu3O2Z0QfCd6Y8
:
uid = CCsBUu3O2Z0QfCd6Y8
This returns just two events:
{"_path":"dns","_system_name":"SmartPCAP_192_168_5_1","_write_ts":"2022-02-18T16:07:44.147273Z",
"ts":"2022-02-18T16:07:44.146859Z","uid":"CCsBUu3O2Z0QfCd6Y8","id.orig_h":"10.9.18.101",
"id.orig_p":52060,"id.resp_h":"10.9.18.1","id.resp_p":53,"proto":"udp","trans_id":39459,
"rtt":0.00041413307189941406,"query":"mail.aepl.com.pk","qclass":1,"qclass_name":"C_INTERNET",
"qtype":1,"qtype_name":"A","rcode":0,"rcode_name":"NOERROR","AA":false,"TC":false,"RD":true,
"RA":true,"Z":0,"answers":["162.250.121.176"],"TTLs":[5.0],"rejected":false}
{"_path":"conn","_system_name":"SmartPCAP_192_168_5_1","_write_ts":"2022-02-18T16:07:54.147004Z",
"ts":"2022-02-18T16:07:44.146859Z","uid":"CCsBUu3O2Z0QfCd6Y8","id.orig_h":"10.9.18.101",
"id.orig_p":52060,"id.resp_h":"10.9.18.1","id.resp_p":53,"proto":"udp","service":"dns",
"duration":0.00041413307189941406,"orig_bytes":34,"resp_bytes":50,"conn_state":"SF",
"local_orig":true,"local_resp":true,"missed_bytes":0,"history":"Dd","orig_pkts":1,
"orig_ip_bytes":62,"resp_pkts":1,"resp_ip_bytes":78,"corelight_shunted":false,
"orig_l2_addr":"00:08:02:1c:47:ae","resp_l2_addr":"20:e5:2a:b6:93:f1",
"spcap.url":"https://192.168.5.1/spcap/v1/?uid=CCsBUu3O2Z0QfCd6Y8",
"spcap.rule":6,"spcap.trigger":"all-unencrypted","community_id":"1:xd/MFWG+2N7nVcDr5rAJjgE3Jaw="}
By comparison, CTYqn61mJNPJsIVG96
returns over 15,000
events
Using the uid
field enables you to tie multiple
streams of events together. When diagnosing errors or attacks this can
aid in collecting identical items together.
